| MODEL |
EBA-2 |
| Inverter Model |
5KW DC48V |
| Rated Output Power |
5000W |
| Output Voltage Waveform |
Pure Sine Wave |
| Output Voltage Regulation |
230Vac+5% |
| Output Frequency |
60Hz or 50HZ |
| Peak Efficiency |
>93% |
| Overload Protection |
60S@102%~110% load;10s@110%~130% load;3s@130%~150 load;200ms@≥150% load |
| Surge Capacity |
2 x rated power for 5 seconds |
| Nominal DC Input Voltage |
48Vdc |
| Cold start Voltage |
46.0Vdc |
| Low DC Warning Voltage |
44.0Vdc |
| Low DC Cut-off Voltage |
42.0Vdc |
| High DC Recovery Voltage |
58Vdc |
| High DC Cut-off Voltage |
61Vdc |
| Charge Mode Specifications |
|
| Charging Current @ Nominal Input Voltage |
5KW:1~80A |
| Absorption
Voltage |
AGM/FLD/LIB/CUS Battery：50vdc |
| Flooded battery: 50vdc |
| Floatingcharging
voltage |
AGM/FLD/LIB/CUS Battery：54.8Vdc |
| Flooded battery: 54.8Vdc |
| Bulk charging
voltage(C.V voltage) |
AGM/FLD/LIB/CUS Battery：57.6Vdc |
| Flooded battery: 56.8Vdc |
| Charging Algorithm |
17-Step(Battery Type , AGM/FLD/LIB/CUS Battery) |
| Solar Charging Mode |
|
| Rated Power |
5000W |
| MPPT charger |
60A |
| solar charging current |
80A |
| Max,PV Array Open Circuit Voltage |
450Vdc max |
| PV Array MPPT Voltage Range |
120-430Vdc |
| Min battery voltage for PV charge |
34Vdc |
| Standby Power Consumption |
2W |
| Line mode charger |
|
| charging current |
60A 80A |
| Line Voltage Range |
90~280VAC(APP mode);170~280VAC(UPS mode) |
| Battery Voltage Accuracy |
+/-0.3% |
| Voltage Accuracy |
+/-2V |
| Charging Algorithm |
17-Step(Battery Type ,AGM/FLD/LIB/CUS Battery) |
| Joint Utility and Solar charging |
MPPT |
| Max Charging Current |
120A |
| Default Charging Current |
60A |
| Battery Model |
EBA-2 |
EBA-2 |
EBA-2 |
| Total Energy |
5.12kWh |
10.24kWh |
5.12kWh |
| Capacity |
100Ah |
200Ah |
300Ah |
| Nominal Voltage |
51.2V |
51.2V |
51.2V |
| Float Voltage |
56V |
56V |
56V |
| Equalization Voltage |
57.6V |
57.6V |
57.6V |
| Discharge Cutting Voltage |
44.8V |
44.8V |
44.8V |
| MAX.Charge & Discharge Current |
100A |
100A |
100A |
| MAX C Rating |
1C |
1C |
1C |
| Dimension |
740x588x195mm |
1170x588x195mm |
1600x588x195mm |
| Net Weight |
65kg |
115kg |
165kg |
| Communication Ports |
CAN,RS485,RS232 |
| Charging Temp Range |
0~55 |
| Disharging Temp Range |
-10~55 |
| Parallel |
Support |
| Cycle Lifes |
≥6000 cycles @80%DOD @25℃ |
| Warranty |
5 years |
| Certifications |
CE,UN38.3,MSDS |
| Function |
WIFI 、Touch Screen |
