| Batteries materials |
Lithium iron phosphate |
| Series parallel mode (S series, P parallel): |
120S1P |
| Nominal voltage |
384V |
| Nominal capacity |
27Ah |
| Size(mm) |
520×230×1060 |
| Weight |
<100kg |
| Color |
Optional |
| Parallel support |
Parallel terminals are supported |
| Output port mode |
terminal |
| Charging way |
CC/CPVP |
| Charging current |
0.5C(standard) |
| Maximum charging current |
1C @25C |
| Charge cut-off voltage |
438Vdc |
| Discharge way |
CC/CPVP |
| Discharge current |
0.5C(standard) |
| Maximum discharge current |
1C @25C |
| Discharge cut-off voltage |
336Vdc |
| Indicator |
LED |
| Communication interface |
RS485/RS232/CAN |
| Charging operating temperature |
0~+50℃ |
| Discharge operating temperature |
–20~+55℃ |
| Warranty |
5 years |
