| MODEL |
EBW-15/51.2 |
| Total Energy(kWh) |
15.36 |
| Capacity(Ah) |
300 |
| Nominal Voltage(V) |
51.2 |
| Float Voltage(V) |
56 |
| Equalization Voltage(V) |
57.6 |
| Discharge Cutting Voltage(V) |
44.8 |
| MAX.Charge & Discharge Current(A) |
200 |
| MAX C Rating |
0.6C |
| Dimension(mm) |
817x500x277 |
| Net Weight(kg) |
121 |
| Scalable |
1~16 in parallel |
| Communication Ports |
CAN,RS485,RS232 |
| Communicated Inverter |
Goodwe/Victron/Sofar/Deye/Voltronic /Pylon /Luxpower Afore/Must/Sako/ |
|
Sorotec/ Sma/ Solis / Phocos /Kstar / Mpp Solar /Growatt/Megarevo/Srne |
| Charging Temp Range(℃) |
0~55 |
| Disharging Temp Range(℃) |
-10~55 |
| Cycle Lifes |
≥6000 cycles @80%DOD @25℃ |
| Warranty |
5 years |
| Certifications |
CE,UN38.3,MSDS |
| Function |
WIFI,Breaker,Equalizer,Bluetooth(optional) |
