| MODEL |
EBL-12-09 |
EBL-12-18 |
EBL-12-30 |
EBL-12-50 |
EBL-12-100 |
EBL-12-150 |
EBL-12-200 |
EBL-12-300 |
| Cell |
Lithium iron phosphate |
| Nominal voltage |
12.8V |
12.8V |
12.8V |
12.8V |
12.8V |
12.8V |
12.8V |
12.8V |
| Nominal capacity |
9Ah |
18Ah |
30Ah |
50Ah |
100Ah |
150Ah |
200Ah |
300Ah |
| Energy |
115.2Wh |
230Wh |
384Wh |
640Wh |
1280Wh |
1920Wh |
2560Wh |
3840Wh |
| Cycle life |
≥6000 cycles @80%DOD @25℃ |
| Series parallel mode |
4S1P |
4S1P |
4S2P |
4S1P |
4S1P |
4S1P |
4S1P |
4S1P |
| Operating temperature |
Charging O~+55 |Humidity 15%~75%|Storage 10~+50 |
| Protection |
Electronic circuit breaker,BMS voltage protection,current limiting |
| Water dust resistance |
IP65 |
| Net Weight(kg) |
1.02 |
2 |
3.5 |
5.28 |
10.3 |
14.9 |
19.5 |
26.5 |
| Size(mm) |
151*94*65 |
180*168*74 |
231*145*211 |
231*145*211 |
339*185*218 |
483*170*240 |
502*186*243 |
502*186*243 |
| Function |
Bluetooth,Led Screen (optional) |
