| MODEL |
EBS-3-5 |
EBS-3-10 |
EBS-3-15 |
EBS-3-20 |
| Total Energy(kWh) |
4.8 |
9.6 |
14.4 |
19.2 |
| Number of batteries |
1 |
2 |
3 |
4 |
| Capacity(Ah) |
100 |
200 |
300 |
400 |
| Nominal Voltage(V) |
48 |
48 |
48 |
48 |
| Float Voltage(V) |
52.5 |
52.5 |
52.5 |
52.5 |
| Equalization Voltage(V) |
54 |
54 |
54 |
54 |
| Discharge Cutting Voltage(V) |
42 |
42 |
42 |
42 |
| MAX.Charge & Discharge Current(A) |
100 |
100 |
100 |
100 |
| MAX C Rating |
1C |
1C |
1C |
1C |
| Dimension(mm) |
620x460x195 |
620x460x390 |
620x460x585 |
620x460x780 |
| Single Battery Net Weight(kg) |
50 |
| Scalable |
1~16 in parallel |
| Communication Ports |
CAN,RS485,RS232 |
| Communicated Inverter |
Goodwe/Victron/Sofar/Deye/Voltronic /Pylon /Luxpower Afore/Must/Sako/Sorotec/ Sma/ Solis / Phocos /Kstar / Mpp Solar /Growatt/Megarevo/Srne |
|
| Charging Temp Range(℃) |
0~55 |
| Disharging Temp Range(℃) |
-10~55 |
| Cycle Lifes |
≥6000 cycles @80%DOD @25℃ |
| Warranty |
5 years |
| Certifications |
UL,CE，MSDS，UN38.3 |
