| MODEL |
EBWT-3/5 |
EBWT-3/10 |
EBWT-3/15 |
| Total Energy(kWh) |
5.12 |
10.24 |
15.36 |
| Capacity(Ah) |
100 |
200 |
300 |
| Nominal Voltage(V) |
51.2 |
51.2 |
51.2 |
| Float Voltage(V) |
56 |
56 |
56 |
| Equalization Voltage(V) |
57.6 |
57.6 |
57.6 |
| Discharge Cutting Voltage(V) |
44.8 |
44.8 |
44.8 |
| MAX.Charge & Discharge Current(A) |
100 |
200 |
200 |
| MAX C Rating |
1C |
1C |
0.6C |
| Dimension(mm) |
693x430x180 |
905x504x195 |
880x478x268 |
| Net Weight(kg) |
52 |
100 |
133 |
| Scalable |
1~16 in parallel(Recommend: 6pcs) |
| Communication Ports |
CAN,RS485,RS232 |
| Communicated Inverter |
Goodwe/Victron/Sofar/Deye/Voltronic /Pylon /Luxpower Afore/Must/Sako/Sorotec/ Sma/ Solis / Phocos /Kstar / Mpp Solar /Growatt/Megarevo/Srne |
|
| Charging Temp Range(℃) |
0~55 |
| Disharging Temp Range(℃) |
-10~55 |
| Cycle Lifes |
≥6000 cycles @80%DOD @25℃ |
| Warranty |
5 years |
| Certifications |
CE,UN38.3,MSDS |
| Function |
WIFI,Breaker,Equalizer,Bluetooth,7 inch Touch Screen |
